Engineering Drawing

Engineering Drawing by S. T. Ghan, D. M. Dharmadhikari

---

Book Summary:

It is indeed a great pleasure and proud privilege for the authors to present this book on the subject "Engineering Drawing" for First Year Diploma in all branches of Engineering and Technology for Semester – II.

This book is strictly written according to the "New Revised Syllabs" of M.S.B.T.E. 'I' Scheme Effective from 2017-18. In this book the complete subject is explained in a lucid manner and particularly by using first angel method of projection. Lots of solved examples with procedure and figures, which include all variety of questions are inculcated in this text book.

Audience of the Book :

This book Useful for Automobile, MechanicalAnd Production diploma students.

Table of Contents:

1. Projection Of Straight Lines And Planes

2. Projections Of Solids

3. Sections Of Solids

4. Sectional Orthographic Views

5. Missing And Auxiliary Views

6. Free Hand Sketches And Conventional Representation
